MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands

MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands

    • MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands
  • MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands

    Product Details:

    Place of Origin: China
    Brand Name: Skywell
    Certification: SGS
    Model Number: U36T01750-36

    Payment & Shipping Terms:

    Minimum Order Quantity: 100㎡
    Price: USD10/㎡
    Packaging Details: Polyester bag and foam rolling inside,Paper carton out of packing size 121cm*42cm*40cm
    Delivery Time: 5-8 days
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 100000㎡ per month
    Contact Now
    Detailed Product Description
    FAW: 175g/㎡ RC: 36%
    Thickness: 0.181mm Total Weight: 273g/㎡
    Tensile Strength: 4410MPA Strength Modulus: 345GPA
    Resin System: #4177 Carbon Fiber: MS40,M35J
    Scrim: No
    High Light:

    prepreg carbon fiber

    ,

    carbon fiber fabric roll

    MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands



    1. What is the feature of carbon fiber ?



    Carbon Fiber's Specisal Features and Characterizing Performances

    1>. Light in Weight and Strong (Mechanical Performances)

    2>. Excellent Dimensional Stability and Heat Resistance (Thermal Characteristics)

    3>. Highly Electric Conductive and Excellent EMI Shielding Propaerty

    4>. Magnificant X-ray Permeability



    2. How to get Pan type carbon fiber  ?



    Carbon Fibers are manufactured by production processes as illustrated below. Manufacturers produce the fibers under different processing conditions to get assortments of products qualities.





    MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands 0



    3. To be suit for different manufacturer progress.



    MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands 1

    4. Application:



    • Sporting goods : Golf shafts , Fishing Rods, Bicycle parts , Etc
    • Industrial Applications :  Composite Robot Hands and Other LCD / Semiconductor Application ,Composite roller  ,Automotive parts ,Electronic Application, Etc.

    MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands 2







    5. Resin system :





    Resin No. Resin Type Curing Temperature ℃ Features & applications
    #450 Epoxy 130 High flex ,impact resistant,Fishing rob,Golf,rolling tube
    #469 Epoxy 130 General industry,sporting equipment, bicycle frame,bicycle rims,Racket,hockey stick
    #477 Epoxy 130 The better improved type than #469,Used in low RC ,high carbon modulus ,And for products with higher quality.Superior impact resistant ,better transparency,self-adhesive, sporting products like bike,racket,hockey,golf etc
    #4177 Epoxy 135 Used in low RC ,high carbon modulus ,And for products with higher quality.Superior impact resistant ,half of transparency, higher self-adhesive
    #4619 Epoxy 135 Not suitable for products asked by nice transparency apperance,And lower resin loss rate, general sporting products
    #502AB Epoxy 130 Specially Designed for impact resistant, the #502A Most used in non-transparency products , And #502B used in transparency products ,like safe helmet
    #3016TG Epoxy 160 impact resistant,most suitable for products that needs high temperature resistant,like road bicycle rims ,braking system
    #3017TG Epoxy 180 Be suitable for products that needs high temperature resistant,flame retardant, TG point for 180℃ to 190℃
    #8005 Epoxy 180 Aircraft,PC products,Flame retardant, high standard under Germany DIN5510-2 ,And United State UL94V0.

    MS40 / M35J Carbon Fiber Prepreg Impact Resistant For Composite Robot Hands 3

    6. Carbon Fiber Specification :



    Type Tickness FAW (g/㎡) RC (%) Total weight (g/㎡) Tensile strength (MPA) Tensile Modulus (GPA)
    U36T01750-36 0.181 175 36 273 4410 345







    7. Packing and Storage.



    Skywell Carbon prepreg packing and storage
    Standard length Unidirectional prepreg:100 m
    Woven prepreg :50 or 100m
      The prepreg is rolled around on paper tube with a silicon -coated separation paper
    Packing data And the roll is packed in a sealed polyethylene bag to prevent moisture absorption
      Diameter of paper tube for unidirectional prepreg :300mm of inner diameter
      Diameter of paper tube for unidirectional prepreg :300mm of inner diameter
      Storage temperature 130℃ curing grade 180℃ curing grade
      .-18℃ or less 6 months 6months
    Storage life 5℃ or less 3 months 2months
      20℃ or less 1.5 months 14days
      The 180℃ curing type is shipped by refrigerated container(-18℃ or less) ,
    SHIPMENT The 130℃ curing type is shipped on regular trucks unless else requested
