High Silica Fiberglass Fabric Silicone Coated Glass Cloth 0.69 Mm Thickness

High Silica Fiberglass Fabric Silicone Coated Glass Cloth 0.69 Mm Thickness

  • High Silica Fiberglass Fabric Silicone Coated Glass Cloth 0.69 Mm Thickness
  • High Silica Fiberglass Fabric Silicone Coated Glass Cloth 0.69 Mm Thickness
  • High Silica Fiberglass Fabric Silicone Coated Glass Cloth 0.69 Mm Thickness
  • High Silica Fiberglass Fabric Silicone Coated Glass Cloth 0.69 Mm Thickness
High Silica Fiberglass Fabric Silicone Coated Glass Cloth 0.69 Mm Thickness
Product Details:
Place of Origin: China
Brand Name: Skywell
Certification: SGS
Model Number: 0500S02
Payment & Shipping Terms:
Minimum Order Quantity: 100m
Price: USD5 PER METER
Packaging Details: Paper Rolling inside and Paper box outside
Delivery Time: 3-5 days
Payment Terms: L/C, T/T, Western Union,Paypal
Supply Ability: 100000m Per month
Contact Now
Detailed Product Description
Materials: Fiberglass +Silica Type: 0500S02
Total Weight G/m2: 680 Thickness: 0.69 Mm
Width: 915-1500mm Service Temperature: 900°C
Sio2 Content: 75 Weave: 8 HS
Highlight:

silicone coated fiberglass cloth

,

silicone coated glass cloth

High Silica Fiberglass Fabric Silicone Coated Glass Cloth 0.69 Mm Thickness



1. Description

  • Hige silica cloth  is a high performance textile fabric  that contains 75% to 98% of SiO2,
  • which organizational structure and high flexibility design is pretty well
  • To be used in the high temperature of strict considtons,used in high temperature heat insulation ,heat protection,not burning, not corruption and has the resistant to acid
  • In 1000 °C  Celsius temperature considtons ,it works well
  • Custom as requiremet to add vermiculite ,silicon coating.





Type Coating  Sio2  content  % Total Weight g/m2 Tickness (mm) Width (mm) Service Tem °C
0500S02 / 75 680 0.69 915-1500 900
0500S02-A / 96 600 0.69 915-1500 1100
0500S04 / 75 1400 1.40 915-1500 900
0500S04A / 96 1200 1.40 915-1500 1100
0508S02LB-A / 96 620 0.60 915-1500 1100
0508S04LB-A / 96 1220 1.40 915-1500 1100



2. Application :

  • Fire door
  • Used for heat preservation and thermal insulation
  • Welding / cutting , molten metal splash protection
  •  Hose and cable protection and under emergency as fire blankets

3. Available Cutom made :

    Can be customized as requirement.



4. Refractory temperature:

    900°C to 1100°C







High Silica Fiberglass Fabric Silicone Coated Glass Cloth 0.69 Mm Thickness 0High Silica Fiberglass Fabric Silicone Coated Glass Cloth 0.69 Mm Thickness 1High Silica Fiberglass Fabric Silicone Coated Glass Cloth 0.69 Mm Thickness 2High Silica Fiberglass Fabric Silicone Coated Glass Cloth 0.69 Mm Thickness 3
